Conquest 100W
LED Street Lighting









The Conquest 100W is a high performance IP65/IP66 rated street light optimised for high uniformity and maximum spacing’s between columns.
Manufactured with anti-corrosion die cast aluminium, stainless steel fixings and featuring high impact glass for additional protection.
Complete with adjustable spigot for side or column top entry, and 10M of cable for a quick installation.
Options include Nema socket, Dali Driver, LED colour temperature, and spigot size.
Code | Description |
LED Rating (lm) |
Total Wattage (W) |
Lum. Flux (lm) |
Lum. Efficacy (lm/W) |
---|---|---|---|---|---|
Conquest - 100W - Standard - Grey - 76mm Spigot | |||||
CQ100-A5C-00G-76 | Conquest-100W-LED-AC-6K-Std-Grey-76mm | 14,656 | 100 | 12,897 | 129 |
CQ100-A5N-00G-76 | Conquest-100W-LED-AC-4K-Std-Grey-76mm | 14,656 | 100 | 12,897 | 129 |
CQ100-A5W-00G-76 | Conquest-100W-LED-AC-3K-Std-Grey-76mm | 12,399 | 100 | 10,911 | 109 |
Conquest - 100W - Standard - Grey - 60mm Spigot | |||||
CQ100-A5C-00G-60 | Conquest-100W-LED-AC-6K-Std-Grey-60mm | 14,656 | 100 | 12,897 | 129 |
CQ100-A5N-00G-60 | Conquest-100W-LED-AC-4K-Std-Grey-60mm | 14,656 | 100 | 12,897 | 129 |
CQ100-A5W-00G-60 | Conquest-100W-LED-AC-3K-Std-Grey-60mm | 12,399 | 100 | 10,911 | 109 |
Conquest - 100W - Standard - Grey - Nema Socket - 76mm Spigot | |||||
CQ100-A5C-06G-76 | Conquest-100W-LED-AC-6K-Std-NemaSocket-Grey-76mm | 14,656 | 100 | 12,897 | 129 |
CQ100-A5N-06G-76 | Conquest-100W-LED-AC-4K-Std-NemaSocket-Grey-76mm | 14,656 | 100 | 12,897 | 129 |
CQ100-A5W-06G-76 | Conquest-100W-LED-AC-3K-Std-NemaSocket-Grey-76mm | 12,399 | 100 | 10,911 | 109 |
Conquest - 100W - Standard - Grey - Nema Socket - 60mm Spigot | |||||
CQ100-A5C-06G-60 | Conquest-100W-LED-AC-6K-Std-NemaSocket-Grey-60mm | 14,656 | 100 | 12,897 | 129 |
CQ100-A5N-06G-60 | Conquest-100W-LED-AC-4K-Std-NemaSocket-Grey-60mm | 14,656 | 100 | 12,897 | 129 |
CQ100-A5W-06G-60 | Conquest-100W-LED-AC-3K-Std-NemaSocket-Grey-60mm | 12,399 | 100 | 10,911 | 109 |
Conquest - 100W - Dali - Grey - 76mm Spigot | |||||
CQ100-A5C-20G-76 | Conquest-100W-LED-AC-6K-Dali-Grey-76mm | 14,656 | 100 | 12,897 | 129 |
CQ100-A5N-20G-76 | Conquest-100W-LED-AC-4K-Dali-Grey-76mm | 14,656 | 100 | 12,897 | 129 |
CQ100-A5W-20G-76 | Conquest-100W-LED-AC-3K-Dali-Grey-76mm | 12,399 | 100 | 10,911 | 109 |
Conquest - 100W - Dali - Grey - 60mm Spigot | |||||
CQ100-A5C-20G-60 | Conquest-100W-LED-AC-6K-Dali-Grey-60mm | 14,656 | 100 | 12,897 | 129 |
CQ100-A5N-20G-60 | Conquest-100W-LED-AC-4K-Dali-Grey-60mm | 14,656 | 100 | 12,897 | 129 |
CQ100-A5W-20G-60 | Conquest-100W-LED-AC-3K-Dali-Grey-60mm | 12,399 | 100 | 10,911 | 109 |
Conquest - 100W - Dali - Grey - Nema Socket - 76mm Spigot | |||||
CQ100-A5C-26G-76 | Conquest-100W-LED-AC-6K-Dali-NemaSocket-Grey-76mm | 14,656 | 100 | 12,897 | 129 |
CQ100-A5N-26G-76 | Conquest-100W-LED-AC-4K-Dali-NemaSocket-Grey-76mm | 14,656 | 100 | 12,897 | 129 |
CQ100-A5W-26G-76 | Conquest-100W-LED-AC-3K-Dali-NemaSocket-Grey-76mm | 12,399 | 100 | 10,911 | 109 |
Conquest - 100W - Dali - Grey - Nema Socket - 60mm Spigot | |||||
CQ100-A5C-26G-60 | Conquest-100W-LED-AC-6K-Dali-NemaSocket-Grey-60mm | 14,656 | 100 | 12,897 | 129 |
CQ100-A5N-26G-60 | Conquest-100W-LED-AC-4K-Dali-NemaSocket-Grey-60mm | 14,656 | 100 | 12,897 | 129 |
CQ100-A5W-26G-60 | Conquest-100W-LED-AC-3K-Dali-NemaSocket-Grey-60mm | 12,399 | 100 | 10,911 | 109 |
Legend: Std = Standard. Dali = Dali Driver. 6K = Cool White (6000K). 4K = Neutral White (4000K). 3K = Warm White (3000K). CW = Cool White. NW = Neutral White. WW = Warm White.
Options: Black Housing = Change 00G to 00B. Optic 1 = Add ‘-1’ at the end of the code. Optic 2 = Add ‘-2’ at the end of the code. Optic 3 = Add ‘-3’ at the end of the code.
NB: Nema Photocell not included with Nema Socket, to purchase separately, use code: LIT-0010.
Features & benefits
- LED rating 14,656lm (6000K & 4000K).
- LED rating 12,399lm (3000K).
- Luminaire flux 12,897lm (46000K & 4000K).
- Luminaire flux 10,911lm (3000K).
- Total wattage 100W.
- 6000K (CW), 4000K (NW) and 3000K (WW) colour temperature.
- IP65/IP66/IK08 rated.
- -20 to +40°C operating temperature.
- LED life span > 100,000hrs.
- Standard weight 8.25Kg.
- Osram LED and Osram Driver.
- Post–top or side–entry, 60/76mm spigot options.
- Aluminium die-casting housing for maximum heat dissipation.
- Corrosion resistant polyester powder coating.
- Optimised optics for high uniformity and maximum spacing’s between columns.
- Future proof design.
- Compliant with Dark Skies recommendations (3K option).
- Bat & Insect friendly (3K option).
*NB: IP66 as standard, IP65 when fitted with Nema socket.
Conquest 100W [6000K – Cool White and 4000K – Neutral White]:
IP65/IP66 Rated LED Street Light with Aluminium die-casting housing and IK08 High Impact glass. Power off protection, 10KV Surge protection and Open Circuit Protection included – Size: 691mm x 305mm x 135mm. 100W with 14,656lm LED Rating and minimum Luminaire Flux of 12,897lm from 16 x [4000K / 6000K] High Power LEDs @ 365ma. To contain [Nema Socket] and fitted with [60/76mm] spigot adaptor – as Gemma Lighting – Conquest 100W.
Conquest 100W [3000K – Warm White]:
IP65/IP66 Rated LED Street Light with Aluminium die-casting housing and IK08 High Impact glass. Power off protection, 10KV Surge protection and Open Circuit Protection included – Size: 691mm x 305mm x 135mm. 100W with 12,399lm LED Rating and minimum Luminaire Flux of 10,911lm from 16 x 3000K High Power LEDs @ 365ma. To contain [Nema Socket] and fitted with [60/76mm] spigot adaptor – as Gemma Lighting – Conquest 100W.
Notes: Delete as required.
